A1 C-frame Single Crank Precision Power Press

Açıklama

·High rigidity frame

·High precision proccessing

·Lower noise

·Locked type six-side long rectangle guides

·Less bending of die height,less deviation of kinetic energy

·Less punching deformation

·Convenient operation

Model  A1-25   A1-45 A1-60 A1-80 A1-110
V H V H V H V H V H
Capacity ton 25 45 60 80 110
Rated tonnage point mm 3.2 2.3 3.2 2.3 4 2.3 5 3.2 5 3.2
Stroke length mm 80 30 110 50 130 50 150 60 180 70
Stroke per minute fixed s.p.m 75 135 65 125 60 120 60 100 50 90
Stroke per minute variable s.p.m 70-110 95-190 50-95 85-175 40-85 80-160 40-75 70-140 30-60 60-120
Max.die heiht mm 230 255 270 300 300 340 330 375 350 405
Slie dimension mm 350x300x50 430x350x60 500x400x70 560x460x70 650x520x80
Bolster dimension mm 720x320x70 850x440x80 900x520x90 1000x600x100 1150x680x110
Slide adjustment mm 50 60 70 80 90
Hole for Punch Shank mm Ø38.1 Ø38.1 Ø50 Ø50 Ø50
stale speed HPxP 4×4 5.5×4 5.5×4 7.5×4 11×4
Inverter VFD-B VFD-B VFD-B VFD-B VFD-B
Slide adjusting motor HPxP Manual Manual  Motorized  Motorized  Motorized
Air Precision Kg/cm² 6 6 6 6 6
Capactiy of die cushion ton 2.6 3.6 6.3 8
Stroke of die cushion mm 60 70 70 80
Arear of die cuaion plate mm² 300×250 350×300 450×310 500×350
Outline dimension mm 832x1060x2165 860x1350x2375 970x1390x2585 1180x1755x2685 1305x1935x2915



A1-125 A1-160 A1-200 A1-250 A1-315 A1-400
V H V H V H V H V H V H
125 160 200 250 315 400
5 3.2 6 4 6 4 6 4 8 6 8 8
180 70 200 80 200 100 250 100 250 100 250 180
50 90 45 80 35 60 30 55 30 40 30 30
30-60 60-120 25-55 50-100 20-50 45-80 20-45 40-70 20-40 30-50 25-35 25-35
370 425 450 510 450 500 450 525 500 575 550 585
700x550x80 700x580x90 850x650x90 920x700x100 1000x720x100 1000x720x100
1200x720x120 1260x760x140 1400x820x160 1550x840x180 1650x880x180 1850x940x200
90 100 110 120 120 120
Ø50 Ø65 Ø65 Ø65 Ø70 Ø70
15×4 15×4 18.5×4 22×4 30×4 37×4
VFD-B VFD-B VFD-B VFD-B VFD-B VFD-B
 Motorized  Motorized  Motorized Motorized Motorized Motorized
6 6 6 6 6 6
8 10 10 14 16 16
80 80 100 100 110 110
500×350 660×420 660×460 600×460 700×460 810×480
1385x2010x3020 1425x2060x3300 1575x2300x3675 1740x2345x4000 1900x2850x4200 2200x3500x4500



Standard accessories Optional accessories
Inverter
Touch pad
Preset counter
Electrical cam Electrical automatic lubrication system
Hydraulic over-load protector pneumatic die cushion device
Handle Silde adjust device(A1-45 below ) Foot switch
Electric Slide adjust device(A1-45 or more) Quick die change device(die lifter, clamp and die arm sepjes)
Mechanical Die height indicator(A1-45 below 60) Slide knock-out device
Electric Die height indicator(A1-45 or more) Die room light
Balance device Photo-electronic safety device
Crank angle indicator Feeder
Electric stroke counter Uncoiler
Air source receptacle Leveler
Against over-run safety device Mechanism hand
Misfeed detection consent
Power socket
Maintenance tool box
Operation Manual
Anti vibration press mount
